Zebra ZT420 Industrial Printer
Quoted on request
Standard Features
- Print Methods – Thermal transfer and direct thermal printing
- Resolution: 203 dpi/8 dots per mm
More Standard Features
• Construction: Metal frame and Bi-fold metal media cover with enlarged clear viewing window
• Side-loading supplies path for simplified media and ribbon loading
• Element Energy Equalizer™ (E3™) for superior print quality
• Communication – USB 2.0, High-Speed, RS-232 Serial, 10/100 Ethernet, Bluetooth 2.1, USB Host
• Back-lit, multiline graphic LCD display with intuitive menu and easy-to-use keypad for quick operation
• Link-OS
• Bi-colored status LEDs for quick printer status
• ENERGY STAR® qualified
Printer Specifications
Resolution:
• 203 dpi/8 dots per mm
• 300 dpi/12 dots per mm (optional)
Memory:
• 256 MB RAM memory (4 MB User Available)
• 512 MB Flash memory (64 MB User Available)
Maximum Print Width: 6.6″/168 mm
Maximum Print Speed: 12 ips/305 mm per second
Media Sensors:
• Dual media sensors – transmissive and reflective
Media Characteristics
Media web width (label and liner):
• 2.00″/51 mm to 7.0″/178 mm Tear/Cutter
• 2.00″/51 mm to 6.75”/171 mm Peel/Rewind
Maximum Non-continuous Label Length: 39″/991 mm
Minimum Label Length:
• Tear-off mode: 0.5″ (12.7 mm)
• Peel mode: 0.5″ (12.7 mm)
• Rewind mode: 0.5″ (12.7 mm)
• Cutter: 1.00″ (25.4 mm)
Print Length
• 203 dpi: 102″/2590 mm
• 300 dpi: 45″/1143 mm
Maximum media roll size: 8.0″/203 mm O.D. on a 3″/76 mm I.D. core
Media thickness: 0.0023″/0.058 mm to 0.010″/0.25 mm
Media types: Continuous, die-cut, notch, black-mark
Ribbon Characteristics
Outside diameter: 450 m: 3.2″/81.3 mm O.D. on a 1.0″/25.4 mm I.D. core
Standard length: 1476′/450 m
Width: 2.00″/51 mm to 6.85″/174 mm
Ribbon setup: Ribbon Wound ink-side out: Ribbon wound ink-side in can be used with the optional ribbon spindle.
Environmental
Operating Environment:
• Thermal transfer: 40º to 104ºF/5º to 40ºC
• Thermal direct: 32º to 104ºF/0º to 40ºC
Storage/Transportation Environment:
• -40º to 140ºF/-40º to 60ºC
Physical Characteristics
Width: 13.25″/336.55 mm
Height: 12.75″/324 mm
Depth: 19.50″/495 mm
Weight: 40 lb./18.14 kg
barcodes/Symbologies
• Linear barcodes: Code 11, Code 39, Code 93, Code 128 with subsets A/B/C and UCC Case Codes, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard 2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code
• 2-dimensional barcodes: Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, TLC 39, MicroPDF, RSS-14 (and composite), Aztec
Options and Accessories
Communication
• Parallel (Bi-directional interface)
• Wireless: ZebraNet® Printer Server – supports 802.11 a/b/g/n networks via an internally integrated option that enables the use of Webview and Alert features
Media Handling
• Rewind: internally rewinds a full roll of printed labels on 3” core, or peels and rewinds liner (Factory installed only)
• Peel – A front mount, passive peel option
• Cutter: A front mount guillotine cutter and catch tray,
RFID
• Supports tags compatible with UHF EPC Gen 2 V1.2/ ISO 18000-6C
• Prints and encodes tags with a minimum pitch of 0.6″/16 mm
• Adaptive Encoding Technology simplifies RFID setup and eliminates complex RFID placement guidelines
Keyboard Display Unit
• Supports KDU Plus™ and ZKDU – Enter variable data and retrieve stored forms for standalone applications
